[Mapping] Add checks at init in TopologicalMapping by hugtalbot · Pull Request #3339 · sofa-framework/sofa

hugtalbot · 2022-09-27T07:02:45Z

Adding check on pointers and type of input/output topology (mostly input) before using them in TopologicalMapping

By submitting this pull request, I acknowledge that
I have read, understand, and agree SOFA Developer Certificate of Origin (DCO).

Reviewers will merge this pull-request only if

it builds with SUCCESS for all platforms on the CI.
it does not generate new warnings.
it does not generate new unit test failures.
it does not generate new scene test failures.
it does not break API compatibility.
it is more than 1 week old (or has fast-merge label).

hugtalbot · 2022-09-27T07:03:14Z

Further to our discussion @epernod @ScheiklP

hugtalbot · 2022-09-27T07:03:35Z

[ci-build][with-all-tests]

alxbilger

Thanks for making this PR. It will improve the UX for sure.

However, I see a lot of duplicated code. I consider it as a technical debt. To discuss if we temporary merge your changes, or think bigger ;)

hugtalbot · 2022-09-28T14:39:55Z

I am open to think bigger, or merge it and then factorize

hugtalbot · 2022-09-29T12:19:12Z

Reviews taken into account 👍 @alxbilger

epernod

I think there is already some checks in TopologyMapping parse method. Checking fromModel and toModel.
Might be the good timing to unify it.
Also it is not possible to put the same message in a single method inside TopologyMapping which is called by the different components.
Using toModel.GetClassName, toModel.getName() etc... ?
Which part of the check is not generic?

epernod

several changes are not compatible with the current api of the topology and some tests are already present in TopologicalMapping create and canCreate methods.

@hugtalbot if you agree I will push a new proposal directly in this PR.

epernod · 2022-10-20T21:47:10Z

+    if (!fromModel)
+    {
+        // If the input topology link isn't set by the user, the TopologicalMapping::create method tries to find it.
+        // If it is null at this point, it means no input mesh topology could be found.
+        msg_error() << "No input mesh topology found. Consider setting the '" << fromModel.getName() << "' data attribute.";
+        modelsOk = false;
+    }


2 remarks regarding this check:

This case is never possible because fromModel is already checked in the mother class TopologicalMapping in the canCreate method. If input and output don't link to valid BaseMeshTopology, the mapping is not create (canCreate return false)

Hopefully this case is never possible because if fromModel is null, printing error message with fromModel.getName() will crash 😄

epernod · 2022-10-20T21:52:16Z

+        if (!dynamic_cast<container::dynamic::TriangleSetTopologyContainer *>(toModel.get()))
+        {
+            msg_error() << "The input topology '" << toModel.getPath() << "' is not homogeneous with a TriangleSetTopologyContainer. The '" << toModel.getName() << "' data attribute must be linked to a valid component, among the following list of eligible components:" << msgendl
+                                   << sofa::core::ObjectFactory::getInstance()->listClassesDerivedFrom<container::dynamic::TriangleSetTopologyContainer>();


I tested what would be the error message. In this mapping case, it is:
data attribute must be linked to a valid component, among the following list of eligible components: TetrahedronSetTopologyContainer, TriangleSetTopologyContainer

which doesn't work, because putting a TetrahedronSetTopologyContainer as output will result in a strange behavior. Not sure if it will crash or if it will be like a "TopologicalIdentityMapping" 🤔

I suggest to move the checks inside a commun method in TopologicalMapping and just test the topologyType of the containters

epernod · 2022-10-20T21:54:54Z

+    else
+    {
+        // Making sure the input topology includes triangle elements
+        if (fromModel.get()->getNbTriangles() != 0)


This could still be valid if we start from an empty mesh and we add progressively triangles with a mapping on the edges... btw I thought I had a test on that.

epernod · 2022-10-25T23:06:00Z

[ci-build][with-all-tests]

hugtalbot · 2022-10-26T09:08:37Z

New approach proposed in the TopologicalMapping to make the checks on input/output topologies. Some missing implementation and find a solution to get the topological element name from enum class. New review needed

…or messages

epernod · 2022-10-26T10:34:25Z

I moved all changes related to TopologicalMapping into the PR #3428 for better clarity.
Therefor this one depends on this new PR.

…TopologicalMapping.h to test input/output

…ing.h

…calMapping

hugtalbot · 2022-10-28T09:53:36Z

If my last question is answered by @epernod (see here), then good to be merged IMO

hugtalbot · 2022-11-02T08:36:43Z

To be rebased once #3428 is merged, then ready

epernod · 2022-11-02T16:34:20Z

et 💥 !!

hugtalbot · 2022-11-02T18:35:42Z

aw aw aw @epernod !

😁

hugtalbot · 2022-11-02T18:38:41Z

it seems mostly to be the case of a grid linked :

The type of the input topology '@../grid' does not correspond to a valid 'Hexahedron' topology.

epernod · 2022-11-02T21:55:57Z

yes and it is "funny" because I had the same issue in #3368
this is just because Grid inherite from MeshTopology which doesn't define the TopoogyType as Hexahedron

fredroy · 2022-11-04T05:34:30Z

Failing scenes were fixed in #3453 a fortiori, lets merge with master and have a final check
